CHAPTER 5: SETUP SOFTWARE
UB25 LINEAR DC RESISTANCE WELDING CONTROL
990-665 5-3
NOTE: The SETUP 2 menu is only
available through the SETUP 1 or SETUP
3 menus.
3 To go to the SETUP 3 menu, press the
▼ (down) key.
NOTE: The SETUP 3 menu is only
available through the SETUP 2 menu.
4 To scroll back through SETUP 2 and
SETUP 1 menus, press the ▲ (up) key.
5 When you have finished programming the desired functions, press the MENU key on the front
panel to return to the MAIN MENU.
1. DISPLAY CONTRAST : 080%
2. BUZZER LOUDNESS : 030%
3. END OF CYCLE BUZZER : OFF
4. UPDATE GRAPH AFTER WELD : ON
5. BUZZER ON WELD STOP : OFF
NUMBER Select, MENU Main menu,
▼▲
1. DO TEST WELD : ALWAYS
2. IGNORE FIRST/LAST : 0.2 ms
NUMBER Select, MENU Main menu, ▲ Page 2
