CHAPTER 5: SETUP SOFTWARE
UB25 LINEAR DC RESISTANCE WELDING CONTROL
990-665 5-25
I.D. Number
The host computer may be used to talk with multiple Power Supplies using a single RS-485
communications line. Each Power Supply sharing that line must have a unique identification number. To
enter an identification number for the Power Supply, proceed as follows:
1 From the MAIN MENU, press the 5 key
to go to the COMMUNICATIONS
MENU.
2 From the COMMUNICATIONS
MENU screen, press the 2 key to get the
I.D. NUMBER entry screen.
3 Enter a two-digit number, from 01 to 99,
in the I.D. NUMBER field.
4 Press the MENU key to get the COMMUNICATION menu screen. This time the I.D. NUMBER
line will display your I.D. number entry.
5 Press MENU to return to the MAIN MENU.
Baud Rate
The baud rate at which the data is sent must match the baud rate of the host computer. To enter the baud
rate, proceed as follows:
1 From the COMMUNICATION menu,
press the 3 key to get the BAUD RATE
selection screen.
2 Use the numeric keypad to select the
baud rate of the receiving device. The
display automatically returns to the
COMMUNICATION
menu which
shows the new baud rate.
3 Press MENU to return to the MAIN MENU.
I.D. NUMBER : 01
NUMBER Change, MENU Previous menu
1. 1200 6. 19.2K
2. 2400 7. 28.8K
3. 4800
4. 9600
4. 14.4K
NUMBER Change, MENU Previous menu
