CHAPTER 5: SETUP SOFTWARE
UB25 LINEAR DC RESISTANCE WELDING CONTROL
5-4 990-665
Section III. Operator Preferences
Display Contrast
1 Go to the SETUP 2 menu.
2 Press the 1 key to access the DISPLAY
CONTRAST adjustment screen.
3 Use the ▲▼ keys to adjust the screen
contrast for comfortable viewing in the
shop environment and different ambient
4 Press MENU to return to the previous screen, or keep pressing the MENU key to return to the
MAIN MENU.
Buzzer Loudness
1 Go to the SETUP 2 menu.
2 Press the 2 key to access the BUZZER
LOUDNESS adjustment screen.
3 Use the ▲ and ▼ keys to adjust the
buzzer tone so that it can be heard
against shop background noise.
4 Press MENU to return to the previous screen, or keep pressing the MENU key to return to the
MAIN MENU.
End of Cycle Buzzer
1 Go to the SETUP 2 menu.
2 Press the 3 key to toggle the end of cycle
buzzer ON or OFF.
NOTE: This function is normally used with
manually actuated weld heads. ON means
that an audible signal will be given at the end
of each weld process to signal the operator to
3 Press the MENU key to return to the MAIN MENU.
DISPLAY CONTRAST : 80%
| |
0 10 20 30 40 50 60 70 80 90
▲▼ Adjust, MENU Previous menu
BUZZER LOUDNESS : 30%
| | | | | | |
0 10 20 30 40 50 60 70 80 90
▲▼ Adjust, MENU Previous menu
1. DISPLAY CONTRAST : 080%
2. BUZZER LOUDNESS : 030%
3. END OF CYCLE BUZZER : OFF
4. UPDATE GRAPH AFTER WELD : ON
5. BUZZER ON WELD STOP : OFF
NUMBER Select, MENU Main menu,
▲▼
To Next Page
