Ammann AP 240 - Machine Lubrication

113AP 240
374018A
374041B
374041A
3
4
1
2
374072B
374076
MAINTENANCE MANUAL
3.6.16. Machine lubrication
Lubricate with grease as per Section 3.2.8.•
Remove oor coverings to make lubrication points acces-•
sible.
Lubricate pin (1). If lever (2) is overhead the horizontal posi-•
tion when braked, then reposition pin (3) into another hole
of pull rod (4).
Shaft joints
External bearings of front wheels
Be careful grease does not get onto ac-
tive surface of brake disc!
