116
AP 240
396247
396248
396249
374079
3.6.
Lubrication and Main
tenance Opera
tions
After 500 hours of operation (6 mon
ths)
3.6.17.
Fuel lter replac
ement
Clean and remove lt
er
.
•
Clean seating face for lt
er
.
•
Apply oil on sealing ring.
•
Fill lt
er with clean fuel.
•
121
