2.7.2. Travel & Reversation
Check both travel controllers (2) are in
idle position, parking brake enabled,
TOTAL STOP (10) not switched on.
Before starting to move the Machine
use horn to give a warning and wait
long enough for any persons present
to leave the hazardous area within the
Machine vicinity in time (area beneath
the Machine)!
Make sure the area in front of and be-
hind the Machine is free and that no per-
sons are within the working reach of the
Machine!
Adjust fuse to ”D”. Turn the controller to select gear 1÷3, se- •
lect direction of running (indicator lamp for enabled work-
place (11) goes ON ), switch OFF parking brake (brake indi-
cator lamp goes o). Increase rpm, use pedal (21) to start
moving the Roller.
Brake and stop the roller with a service brake (22) for speed
•
reduction.
NEVER drive downhill with travel con-
troller in “N“ position (idle). The gear
engaged during downhill driving must
correspond to the gear engaged should
there be uphill driving. (the higher the
slope gradient the lower the gear).
NEVER drive a Roller over 18 tons of its
weight on a slope with gradient over
25 %.
NEVER drive a Roller over 18 tons of its
weight with 2nd and 3rd gear engaged
on a slope that has gradient over 15 %.
NEVER change steering place - shifting
from LH seat to RH one and vice versa
while driving. Stop the Roller, brake it a
then change the seat!
