MAINTENANCE MANU
AL
3.6.14.
Check the engine induc
tion manifold
and air lter sensor
Check pipe hoses and xing of clips.
•
Check air lter cu
. Cov
er suction hole.
•
Start the engine
, turn
o IDLE
switch, increase
engine speed
•
to max, check if pilot lamp lights up
.
114
116
