MAINTENANCE MANUAL
After 1000 hours of operation (1 year)
3.6.22. Check and adjust brake clips
Remove tyre inating and blowing o hose (1) near small •
rotors (2). Remove wheels (3).
Brake o the Roller before wheel remov-
al !
Lift a bit the Machine onto the rear lugs of the frame so the •
rear wheels do not touch the ground. Chock the rear part of
Machine frame. Secure front wheels with Scotch blocks on
both sides.
Remove step by step the brake drums. When removal is •
complicated, use forcing-o screws M12-60 of min. 8G
strength, into holes (1) of brake drum (2). Conrm there are
no scratches or cracks across drum’s internal diameter.
Check thickness, uneven wear or contamination of lining •
(1).
