SPECIFICATION MANUAL
Name plate location
1 - Name plate
2 - Machine frame number
Engine name plate location
The machine that complies with the requirements as to health
protection and safety is identied with a name plate with CE
marking.
1 - Name – always mentioned only in the English version
2 - Type
3 - Version
4 - Serial number
5 - Operating weight
6 - Maximum weight
7 - Rated power
8 - Front axle load
9 - Rear axle load
10 - Year of manufacture
