Ammann AP 240 - Page 36

30 AP 240
2153bz
2428bz
2668bz
3038bz
101
dB
WA
L
3038
3017bz
2687bz
2939
2667bz
ŘETĚZY PRO UCHYCENÍ
NA PLOŠINĚ PŘEPRAVNÍHO
PROSTŘEDKU
CHAINS FOR GRIPPING
ON CONVEYANCE PLATFORM
KETTEN FÜR DIE BEFESTIGING
AUF DER PLATTFORM DES
VERKEHRSMITTELS
ROPS
L = 8m
26ft
min
L =
min
L = 13ft
+
l = 6,4ft
min
L = 4m
min
L = 13ft
min
ROPS
L = 4m
+
l = 1,95m
min
24 t
(52910)
L min
2x 12 000 kg
(2x 26455 lb)
L min
2x 12 000 kg
(2x 26455 lb)
ROZPĚRA l = 1,95 m
THE BRACE l = 6,4 ft
DIE SPREIZE l = 1,95 m
2.1. Main Safety Measures
7. Manual On the seat backrest stowage box.
8. Disconnect Alternator Disconnect alternator before welding on the Machine!
(labelled on dashboard)
9. Danger of explosion Imminent danger of explosion while handling the battery
- read Operation Manual. (Symbol located inside box of
the battery)
10. Fasten the Belt Fasten safety belt before starting to move the Machine.
(symbol located on control panel)
11. Lifting and Rigging Diagram Use rigging of sucient loading capacity. (symbol located
on LH side behind cab)
12. Lifting Lugs Lift the Machine in these lugs. (symbol located near lifting
lugs along both sides of the frame)
13. Noise Emitted External noise of the Machine. (symbol located on frame’s
LH side)
