Ammann AP 240 - Page 55

49AP 240
374039
A
44
41
42
43
2260
596307
596625
374038
А
B
374035
48
49
B
374036
45
47
46
0
MAX
MIN
1 2
3
B
OPERATION MANUAL
A Switches
B Heating - Air Conditioner
Window Washer Switch (41)
Rear Wiper Switch (43)
Front Wiper Switch (42)
Cab Lighting (44)
Fan Switch (45)
Temperature Control (46)
Air Conditioner (optional) (47)
Cabin Induction Air Control (48)
Filter (49)
Do not handle the controllers when
driving.
! CAUTION !
Close ap (48) to avoid any smell to penetrate into
the cabin. Do not keep the ap closed for too long –
fogging up of windows will occur.
