60 AP 240

ADJUST BACKLIGHT

396028

ADJUST BACKLIGHT

396029

ADJUST BACKLIGHT

ADJUST CONTRAST

UTILITIES

396030

ADJUST BACKLIGHT

ADJUST CONTRAST

UTILITIES

396031

2.6. Controllers & Control Instruments

Use CURSOR to adjust backlight intensity

Press MENU to return to main menu

In main menu, move cursor to ADJUST CONTRAST - to adjust

contrast.

Press ENTER to open the item
