Section 5 GPIB
5-2
5.1 Overview
MF2412B/MF2413B/MF2414B comes standard with a GPIB interface that allows you to automatically perform measure-
ments by connecting the unit to a host computer. It also makes it possible to measure short frequency fluctuations such as
VCO startup characteristics using high-speed sampling functions on a host computer.
5.2 Function
MF2412B/MF2413B/MF2414B offers the following functions when using GPIB.
Table 5-1 Functions and Device Messages
Function
Input :
Switching of measurement signal input channels
Input2 attenuator switching
Input2 input impedance switching
Setting of manual frequencies
Switching of frequency acquisition mode
Switching of level acquisition mode
Setting of amplitude discrimination values
Reference signal :
Reference signal selection
Measurement :
Switching of count mode
Switching of hold on/off
Setting measurement resolution
Setting of sample rate
Burst signal :
Switching of burst measurement on/off
Selecting of burst measurement mode
Switching to burst polarity
Switching of burst measurement width
Gate :
Switching of gate end on/off
Setting of gate width
INPCH
ATTN
INP2Z
AF
ACF
ACL
AD
REF
CNTMD
SH
RES
SMP
BST
BSTMD
BSTPL
BSTWDT
GTEND
GTWDT
Device Message
