1-5
1.3.3 Optional Accessories
The following shows MF2412B/MF2413B/MF2414B optional accessories.
Table 1-5 Optional Accessories
Model Name/No.
K224B
34RKNF50
J0060
J0526
J0527
J0127A
J0853
J0854
MP612A
MP613A
J0007
J0008
B0409
B0426A
B0329L
B0390G
B0411A
——Coaxial adapter——
Coaxial adapter
Coaxial adapter
Coaxial adapter HRM553S
Coaxial adapter
——Coaxial cord——
Coaxial cord
Coaxial cord, 1 m
Coaxial cord, 2 m
Coaxial cord, 2 m
——High-frequency fuse——
Fuse holder
Fuse terminal
——Other——
GPIB connection cable, 1 m
GPIB connection cable, 2 m
Carrying case
Carrying bag (soft tipe)
Protective Cover
Rack Mounting
Rack Mounting
K-P
•
K-J, SMAcompatible (DC to 40 GHz, SWR1.2)
Reinforced K-M
•
N-F (DC to 20 GHz, SWR1.25)
N-J
•
SMA-P
N-J
•
SMA-J
K-P
•
K-P (DC to 40 GHz)
BNC-P
•
RG-58A/U
•
BNC-P
Dual-end N-P (20GHz)
Dual-end APC3.5-P (27GHz)
N-P
•
N-J, DC to 1 GHz
Rating +17 dBm, blowout power +35 dBm or more
With protective cover
1/2MW2U
19" type, for single unit
19" type, for 2 parallel units
Part Name Notes
Note 1 :
When connecting or disconnecting the K plug connector for measuring to/from the K connector used on
MF2414B Input 1, make sure that the center pin does not rotate. If you will be frequently connecting or discon-
necting it, insert a coaxial adapter such as K224B between so as to prevent the cable from being damaged.
Note 2 :
If there is the danger of MF2412B/MF2413B/MF2414B being electrically overloaded, input the signal through
the MP612A fuse holder and MP613A fuse terminal to prevent the counter’s internal circuit from being damaged.
Note that because the fuse holder’s connector in shaped like an “N”, you need a adapter that fits the connector
type.
1.3 Unit Configuration
