4.1 Turning on Power/Self Check Screen
The model name shown in the screens is MF2412B. However, MF2413B and MF2414B also use the same screens.
Microwave Frequency Counter
MF2414B
Self-Check executing..
(a) Self-check (simple and detailed) screen
Microwave Frequency Counter
MF2414B
Self-Check completed.
RAM : Pass LCD-C : Pass
GPIB-C : Pass ASIC : Pass
(b) Self-check completed (simple and detailed) screen
Microwave Frequency Counter
MF2414B
Self-Check completed.
RAM : Pass LCD-C : Pass
GPIB-C : Pass ASIC : Fail
(c) Self-check failed (simple) screen
Anritsu MF2414B
---- Self-Check ----
RAM : Pass LCD-C : Pass
GPIB-C : Pass ASIC : Pass
DC : Pass PLL Lock : Pass
Freq Meas : Fail
(d) Self-check failed (detailed) screen
Microwave Frequency Counter
MF2414B
Self-Check completed.
RAM : Pass LCD-C : Pass
GPIB-C : Fail ASIC : Pass
>Press Preset key to continue.
(e) GPIB failed (simple) screen
Fig. 4-1 Self-Check Screens
