Section 4 Unit Operation
4-20
(3) Menu F3: Sets the manual frequency value. Selecting Set Freq by pressing the [Enter] key highlights Manual Freq,
allowing you to set the manual frequency value using the numeric keypad. Figure 17 shows the screen displayed after
you have entered “12”. Pressing the [GHz] key at this point sets 12 GHz as the acquisition frequency value, thus
starting measurements.
20 000 000 0
00
Hz Freq Acq
Manual Freq : 12
Mode
[Manual]
Last
Measure
Set
Freq
Count
[Fast]
Fig. 4-17 Setting Manual Frequency
After you have entered a numeric value and a unit of measure, Manual Freq is highlighted, allowing you to enter
another frequency continuously.
To exit from the numeric input mode, press the [Enter], [<], [>], or [Return to Meas] key.
(4) Menu F4 : Sets the count method to either Fast or Normal.
Pressing F4 when Fast is set will change the setting back to Normal, and change the display to Count [Normal]. When
Fast is set, the unit will perform countings using the reciprocal method. When Normal is set, the unit will perform
countings using direct count method. However, when Meas Mode is set to Burst, the unit will count using the Fast
(reciprocal) setting even if Mode is set to Normal.
To Next Page
