SBC-GX1 Technical Manual
Appendix B – Connector details
PL7 - PS/2 keyboard
Connector: 6-pin Mini-DIN.
Pin Signal
Name
1 KB
DA
T
A
2 No
Connect
3 Ground
4 +5V
5 KB
CLOCK
6 No
Connect
4
2
65
3
1
PL8 - USB ports
Connector: 10 way
, 2.54
mm (0.1”) x 2.54mm (0.1”) dual row pin header
Mating Connector:
Framatome 65043-032
Pin
Signal Name
Pin
Signal Name
1 VBUS-1
2
VBUS-2
3 DNEG-1
4
DNEG-2
5 DPOS-1
6
DPOS-2
7 Ground
8
Ground
9 Ground
10
Ground
91
12
0
PL9 - PS/2 mouse
Connector: 6-pin Mini-DIN.
Pin Signal
Name
1 MS
DA
T
A
2 No
Connect
3 Ground
4 +5V
5 MS
CLOCK
6 No
Connect
4
2
65
3
1
© 2004 Arcom Issue D
86
85
87
