WEB BROWSER-BASED CONFIGURATION
of the disk capacity available in a RAID set. Multiple volume sets
can exist on a group of disks in a RAID set. Additional volume sets
created in a specied RAID set will reside on all the physical disks
in the RAID set. Thus each volume set on the RAID set will have its
data spread evenly across all the disks in the RAID set.
The following is the volume set features for the SAS RAID control-
ler.
1. Volume sets of different RAID levels may coexist on the same
RAID set.
2. Up to 128 volume sets can be created in a RAID set.
3. The maximum addressable size of a single volume set is not
limited to two TB, because the controller is capable of 64-bit LBA
mode. However the operating system itself may not be capable of
addressing more than two TB.
See Areca website ftp://ftp.areca.com.tw/RaidCards/Docu-
ments/Manual_Spec/ Over2TB_050721.ZIP le for details.
6.6.1 Create Volume Set (0/1/10/3/5/6)
To create volume set from RAID set system, move the cursor bar
to the main menu and click on the “Create Volume Set” link. The
“Select The Raid Set To Create On It” screen will show all RAID
set number. Tick on a RAID set number that you want to create
and then click on the “Submit” button.
