• Tag Queuing
This option, when enabled, can enhance overall system perfor-
mance under multi-tasking operating systems. The Command
Tag (Drive Channel) function controls the SAS command tag
queuing support for each drive channel. This function should
normally remain enabled. Disabled this function only when us-
ing older drives that do not support command tag queuing.
3.7.3.2 Create Raid30/50/60 (Volume Set
30/50/60)
To create 30/50/60 volume set from RAID set group, move
the cursor bar to the main menu and click on the “Create
Raid30/50/60” link. The “Select The Raid Set To Create Volume
On It” screen will show all RAID set number. Tick on the RAID
set numbers (same disk No per RAID set) that you want to cre-
ate and then click on it.
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
