WEB BROWSER-BASED CONFIGURATION
112
6.6.2 Create Raid30/50/60 (Volume Set
30/50/60)
To create 30/50/60 volume set from RAID set group, move
the cursor bar to the main menu and click on the “Create
Raid30/50/60” link. The “Select The Raid Set To Create Volume
On It” screen will show all RAID set number. Tick on the RAID
set numbers (same disk No per RAID set) that you want to cre-
ate and then click on the “Submit” button.
The new create volume set attribute allows user to select the
Volume Name, RAID Level, Capacity, Greater Two TB Volume
Support, Initialization Mode, Strip Size, Cache Mode, Tagged
Command Queuing, SCSI Channel/SCSI ID/SCSI Lun. Please
refer to above section for details description of each item.
Note:
ARC-1212 4-port SAS/SATA controller does not support
Raid 30/50/60. There is no action on this conguration
when it is appeared. RAID level 30, 50 and 60 can support
up to eight sub-volumes (RAID set), but it can not support
expansion and migration.
6.6.3 Delete Volume Set
To delete a volume from RAID set, move the cursor bar to the
main menu and click on the “Delete Volume Set” link. The “Select
The Raid Set To Delete” screen will show all RAID set numbers.
Click a RAID set number and the “Conrm The Operation” check
box and then click the “Submit” button to show all volume set
