BIOS CONFIGURATION
57
The created new volume set attribute option allows users to
select the Volume Name, Capacity, RAID Level, Strip Size, SCSI
ID/LUN, Cache Mode, and Tagged Command Queuing. The
detailed description of those parameters can refer to section
3.7.3.1. User can modify the default values in this screen; the
modication procedures are in section 3.7.3.4.
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
Ethernet Conguration
View System Events
Clear Event Buffer
Hardware Monitor
System information
Volume Set Function
Volume Set Functions
Creat Volume Set
Creat Raid30/50/60
Delete Volume Set
Modify Volume Set
Check Volume Set
StopVolume Check
Display Volume Info.
Create Raid30/50/60
Create Raid 30/50/60
[*] Raid Set # 00 1600.0GB 1
[ ] Raid Set # 01 1600.0GB 1
[*] Raid Set # 01 1600.0GB 1
3.7.3.3 Delete Volume Set
To delete volume set from a RAID set, move the cursor bar to
the “Volume Set Functions” menu and select the “Delete Volume
Set” item, then press the Enter key. The “Volume Set Func-
tions” menu will show all Raid Set # items. Move the cursor
bar to a RAID set number, then press the Enter key to show all
volume sets within that RAID set. Move the cursor to the volume
set number that is to be deleted and press the Enter to delete
it.
Note:
ARC-1212 4-port SAS/SATA does not support Raid
30/50/60. There is no action on this conguration when it
is appeared.
Note:
ARC-1212 4-port SAS/SATA controller does not support
Raid30/50/60. There is no action on this conguration
when it is appeared. RAID level 30, 50 and 60 can not
support expansion and migration.
