Arkray PU-4010 - Start up; Turning on the Power; Turning off the Power

PU-4010 2-4
2-3-1 Turning On the Power
Press and hold the button until the power turns on.
• A short beep will sound and the display will change as shown below.
• The test strip holder will extend from the
right of the instrument
REFERENCE: For left-handed users, the
instrument can be set so that the test strip
holder extends from the
left. See “1-4-5.
Changing the Direction of the Test Strip
Feeding” on page 1-15.
Make sure the standby screen appears at
the end of warm-up.
Go to “2-4. Test Conditions Setup” on the
next page.
2-3-2 Turning Off the Power
Press and hold the button for three seconds or more.
• The test strip holder will retract inside the instrument and the display will turn off.
REFERENCE: If the instrument is inactive for three consecutive minutes, it will automatically
turn itself off.
2-3 Start Up
1
All indications Version Date Time
Test strip
holder
Standby screen
2
