4.5.5 SYS_CFGSTAT Register
The SYS_CFGSTAT Register characteristics are:
Purpose
The SYS_CFGSTAT Register contains system configuration status information about read and
write operations between the application software in the FPGA and the MPS2 or MPS2+ Board
board peripherals.
Usage constraints
The SYS_CFGSTAT Register is read-only.
Configurations
Available in all MPS2 and MPS2+ configurations.
The following figure shows the bit assignments.
31
0
00
Reserved
Configuration error
Configuration complete
Figure 4-11 SYS_CFGSTAT Register bit assignments
The following table shows the bit assignments.
Table 4-12 SYS_CFGSTAT Register bit assignments
Bits Name Function
[31:2] - Reserved. Do not write to these bits.
[1] Configuration error A write to SYS_CFGCTRL clears this bit.
• 0b0 Configuration successful
• 0b1 Configuration failed
[0] Configuration complete A write to SYS_CFGCTRL clears this bit.
• 0b0 Configuration not complete
• 0b1 Configuration complete
Related information
4.3 Register summary on page 4-62
4 Programmers Model
4.5 System configuration registers
100112_0200_09_en Copyright © 2013–2016, 2018–2020 Arm Limited or its affiliates. All
rights reserved.
4-73
Non-Confidential
