Optics 137
Note: Due to the optical mirror shutter, the use of Angenieux Optimo Rouge lenses,
any Super16 lenses, or lenses with dimensions not matching the dimensions in the
figure "Allowed lens dimensions with mirror shutter" drawing cannot be used with the
ALEXA Studio, as they would destroy the rotating mirror shutter!
Figure 100: Allowed lens dimensions with mirror shutter
14.3.3 Optical Viewfinder
The ALEXA Studio has an optical reflex viewfinder system with
interchangeable ground glasses.
It offers an exceptional viewing quality favoured by a large optical design.
Special care has been taken to avoid the unpleasant vignette effect that
could occur by moving the eye.
