Minimum Equipment Recommended For Operation 27
8 Installation of The Camera
8.1 Minimum Equipment Recommended
For Operation
ARRI ALEXA camera body including SxS module and Lens Adapter
PL mount without LDS (LA-PL-1)
EVF-1 Electronic Viewfinder
VMB-1 Viewfinder Mounting Bracket
KC 150-S Viewfinder Cable short 0.35m/1.2ft
CCH-1 Center Camera Handle
BP-12 Bridge Plate with base plate, or BPA-1 with BP-5/BP-8 Bridge
Plate and base plate, or WA-1 Wedge Adapter and Quick Release HD
Baseplate
SD card
Compatible power supply
Sony SxS PRO card for recording
8.2 Tripod and Remote Heads
Tripod and remote heads used with ALEXA have to provide enough load
capacity to support the camera and attached accessories. The table to the
right shows the camera weight for different components.
Note: Check for the payload of remote heads and cranes.
In applications where the camera mount is subject to high forces (e.g. car or
helicopter mounts) the camera must be additionally secured with retaining
cords. All fastening screws must be tightened firmly with an appropriate
screwdriver (not with the commonly used coin!).
Camera weight lbs kg
ARRI ALEXA incl. SxS module, EVF-1, VMB-1,
CCH-1, KC-150S
16.85 7.65
ALEXA camera body including SxS module 13.79 6.26
Electronic Viewfinder EVF-1 1.65 0.75
Viewfinder Mounting Bracket VMB-1 0.55 0.25
