34 Installation of The Camera
Figure 17: SCH-1
Figure 18: Camera with SCH-1, side view
8.6 Bridge Plates BP-12/BP-13
The bridge plate BP-12 for 19 mm studio rods has been newly developed for
ALEXA. It mounts directly to the camera housing with two screws and
ensures that support rods, matte boxes and follow focus units are positioned
properly in regards to the optical center of the camera, just like all other
ARRI cameras.
