24 Power Supply
Attaching the battery to the adapter
Place the battery with the V-shaped wedge into the adapter so that the
wedge sits right above its counterpart of the mount.
Move the battery downwards until you hear a snap.
Make sure it is connected correctly and sits tight.
Releasing the battery
When facing the battery, press the button located on the mount on the
left side. Some batteries have an additional top-release mechanism.
Move the battery upwards and remove it.
Figure 8: ALEXA with BAB-V and V-Mount battery
Note: Not all V-Lock batteries deliver enough power to supply the camera. We
recommend to not use any batteries with a capacity of less than 90 Wh to prevent
damage to the battery and unpredictable camera behavior. Any camera-battery
combination should be tested prior to use, especially when accessories are powered
through the camera.
