Aspen Avionics Evolution EFD1000 VFR PFD - Ground Speed; Outside Air Temperature (When Enabled)

CHAPTER 4 REFERENCE GUIDE
EFD1000 VFR PFD Pilot’s Guide
Page 4-21
091-00028-001 ( )
Select the Transition Setting
1. Press the MENU Button and rotate the Right Knob to the GENERAL SETTINGS
C page.
2 Press the MACH DSPL Hot Key and rotate the Right Knob to the desired
Altitude or Speed setting.
3. Press the MENU Button to exit.
4.3.2. Ground Speed
The Ground Speed (GS) comes from a congured GPS navigator and is digitally
displayed in the lower left corner of the Data Bar with a value range of 5–999 knots or
mph, using the same unit of measurement as the Airspeed Indicator.
4.3.3. Outside Air Temperature (when enabled)
The Outside Air Temperature (OAT) is displayed in the center of the Data Bar (Figure
4-36). The temperature is obtained from the temperature sensor located in the RSM.
Temperature sensor ranges from -55°C to +80°C (-67°F to +176°F).
Set OAT Units of Measure
1. Press the MENU Button.
2. Rotate the Right Knob counterclockwise until GENERAL SETTINGS B page
displays.
3. Press the OAT Menu Key.
The Menu label turns magenta and the EDIT VALUE label displays above the Right Knob
(Figure 4-37).
4. Rotate the Right Knob to select either °C or °F (Figure 4-37).
5. Press the MENU Button to exit.
Figure 4-37
Select OAT Units of Measure
