CHAPTER 4 REFERENCE GUIDE
EFD1000 VFR PFD Pilot’s Guide
Page 4-49
091-00028-001 ( )
.
4.7.3. Typical Autopilot Operations
1
Whenever the PFD’s installed conguration includes connections to GPS, VLOC, and
autopilot systems, it acts as a data conduit between the navigators and the autopilot.
This enables any compatible navigator to be coupled to the autopilot.
EFD 1000 VFR provides no vertical auto pilot guidance and is not intended to be
coupled with a multi axis auto pilot.
NOTE
With the autopilot in HDG mode, if GPSS is automatically disabled, the autopilot will roll
wings level; it will not follow the Heading Bug.
Figure 4-112
GPSS Automatically
Disabled — Wings Level Mode
1.
Requires ACU option
