Aspen Avionics Evolution EFD1000 VFR PFD - Hot Keys

CHAPTER 2 CONTROLS AND DISPLAY
EFD1000 VFR PFD Pilot’s Guide
Page 2-10
091-00028-001 ( )
2.2.3. Hot Keys
The ve keys along the lower right side of the PFD function as either single-action
Hot Keys for frequently used commands or as Menu Keys when the Menu has been
activated. The Hot Key functions are accessible at any time, except when the Menu is
active.
Each Hot Key provides instant access to the assigned command. Each press of a Hot Key
toggles between the settings that each key controls (see Table 2-3).
The Hot Key labels use the following color philosophy (see Figure 2-8 and Figure 2-9).
• A green label and dark blue letters (also known as inverse green) indicates
that the Hot Key function is enabled
• A dark blue label and green letters indicates that the Hot Key function is
diabled
• A dark blue label and gray letters indicates that the Hot Key function is not
available
• A dark blue label without letters indicates that the Hot Key has no function
The 360/ARC Hot Key labels indicate which mode is currently active on the Navigation
Display.
NOTE
When congured with the Evolution Hazard Awareness
option, there are two levels of Hot Keys controlled
by the rst Hot Key (1/2 or 2/2). The second level
(2/2) provides access to Hazard Awareness overlays
as described in Chapter 4, Section 4.8. Hazard
Awareness.
NOTE
The TRFC Filter Hot Key is blank when Trac Software
Option is not installed.
