CHAPTER 2 CONTROLS AND DISPLAY
EFD1000 VFR PFD Pilot’s Guide
Page 2-5
091-00028-001 ( )
2.2.1.1. Left Knob Functions
The Left Knob is used to set the Course (CRS) and Airspeed Bug (IAS). Course (CRS) is the
default setting for the Left Knob.
Refer to Table 2-1 and Figure 2-2
• Rotate the Left Knob one click or Press the knob once to set the course (CRS)
(Refs. 46 and 51 and see NOTE about Auto Course)
• Press the Left Knob twice to set the Airspeed Bug (IAS) and Selected Airspeed
Field (Refs. 33 and 34)
2.2.1.2. Right Knob Functions
The Right Knob is used to set Heading (HDG), Selected Altitude Field (ALT), Barometric
Pressure (BARO). Successive presses of the Right Knob will cycle through HDG and ALT
in a round-robin sequence. Rotate the Right Knob to the left or right to decrease or
increase the value of selected eld. Heading (HDG) is the default setting for the Right
Knob.
Refer to Table 2-1 and Figure 2-2
• Rotate the Right Knob one click or Press the knob once to set the Selected
Heading Field/Heading Bug (HDG) (Refs. 52 and 53)
• Press the Right Knob twice to set the Selected Altitude Field (ALT)/Altitude
Bug (Refs. 22 and 26)
NOTE
When the CDI navigation source is selected to a GPS
receiver and the Auto Course is enabled in the Menu,
the course is set automatically by the GPS and is not
pilot-adjustable (see Section 4.4.6). This state is
indicated by the CRS eld and Knob label shown in
green with an inverse “A”. In this case, pressing the Left
Knob will enable you to set only the Airspeed Bug(IAS).
