CHAPTER 2 CONTROLS AND DISPLAY
EFD1000 VFR PFD Pilot’s Guide
Page 2-13
091-00028-001 ( )
2.2.4. Menu
The MENU button is used to access the EFD1000 PFD’s Menu to change options, and
also to change the PFD’s display brightness.
2.2.4.1. Using the Menus
Press the MENU button to activate the Menu (Ref. 3). The current menu page name is
shown on the bottom center of the Navigation Display. Directly below the menu page
name is a segmented menu page bar, giving a graphical representation of the current
page relative to the total number of menu pages. The current menu page number is
shown in the lower right corner of the Navigation Display.
Menu Page 1, General Settings A, is the one most commonly used in ight. It allows
the pilot to enable or disable the AUTO COURSE SELECT mode, to display or hide the
Vspeeds on the airspeed tape, and to choose CDI type for the ARC Compass mode.
The other menu pages are used for barometric pressure and Outside Air Temperature
(OAT) units of measure settings, Auto Range, Vspeeds and map customization, PFD
power management, product version information, and information and option settings,
relative to your specic equipment and installed options.
The Menu operates either in the Navigation or Edit mode, as indicated by the label
directly above the Right Knob. When the MENU button is rst pressed, the Main Menu
is in the Navigation mode, indicated by the magenta label SEL PAGE directly above
the Right Knob (Figure 2-15). When in the Navigation mode, rotating the Right Knob
navigates through the menu pages. Rotate the Right Knob clockwise to advance to the
next menu page, counterclockwise to return to the previous page.
Figure 2-15
Menu Navigation Mode
To Next Page
