2.3.3. Data Bar
The Data Bar visually separates the upper and lower halves of the PFD display. When
available, True Airspeed (TAS) or Mach Number, GPS Ground Speed (GS), Outside Air
Temperature (OAT), Wind Vector arrow, Wind Direction, Wind Speed, and Barometric
Pressure Setting are presented in the Data Bar (Table 2-7 and Figure 2-34).
When any of these values are not available or invalid, the corresponding data eld is
dashed. If the Wind Direction and Speed are not available or invalid the Wind Direction
Arrow is removed. A GPS navigator must be connected and providing valid ground
speed and ground track to display GS and wind data.
The Data Bar is discussed in detail in Section 4.3.
DATA BAR
38 True Airspeed (TAS) or Mach Number
39 Barometric Pressure Setting Field
40 Wind Direction and Speed
41 Wind Direction Arrow
42 Outside Air Temperature (OAT)
43 Ground Speed (GS)
Table 2-7
Data Bar Components
43
38
404142
39
Figure 2-34
Data Bar Components
NOTE
When the winds aloft are less than 10 knots, the wind
data is not displayed.
