Aspen Avionics Evolution EFD1000 VFR PFD - Remote Sensor Module (RSM)

CHAPTER 7 APPENDICES
EFD1000 VFR PFD Pilot’s Guide
Page 7-12
091-00028-001 ( )
7.5.2. Remote Sensor Module (RSM)
Width 2.65 in.
Length 4.40 in.
Height 1.00 in.
Weight 0.2 lbs.
Input Voltage Provided by PFD
Max Current Included in PFD Current
Table 7-2
Remote Sensor Module (RSM) Specications
7.5.3. Analog Converter Unit (ACU)
Width 5.75 in. (including mounting ange)
Length 4.30 in. (including connector)
Height 1.60 in. (including mounting ange)
Weight 0.8 lbs.
Input Voltage +10 to +32 VDC
Max Current 0.5 Amps @ 28 VDC
1.0 Amps @ 14 VDC
Interfaces ARINC-429 and RS-232
Table 7-3
Analog Converter Unit (ACU) Specications
