4.8.3. Trac Overlay
1
The TRFC Hot Key enables the trac display overlaid on the Navigation Display when
the PFD is congured with one of the following trac sensors:
• Avidyne TAS 600/610/620 (TAS)
• Bendix/King KMH 880 (TAS)
• Bendix/King KTA 870 (TAS)
• Garmin GTX 330 (TIS)
• RYAN 9900BX (TAS)
• SKYWATCH SKY 497 (TAS)
• SKYWATCH SKY 899 (TAS)
The TRFC Hot Key enables the Trac Overlay and the selection of a Trac Altitude Filter.
The Hot Key Label is inverse green (green label with dark blue letters) when enabled
(Figure4-127) or a blue label with green letters when disabled.
When the Trac Overlay is enabled, a TRFC annunciation is presented on the lower left
of the Navigation Display. The trac setting that was previously reset over a power cycle
is retained as last congured by the pilot.
Display the Trac Overlay
1. Select the 2/2 Hot Key Menu.
2. Press the TRFC Hot Key to select the desired Altitude Filter.
Figure 4-127
Trac Overlay Enabled
NOTE
Because of their importance, the PFD will show Trac
Advisories on the Navigation Display even when Trac
Overlay is disabled.
1. VFR PFD option
