Aspen Avionics Evolution EFD1000 VFR PFD - Controls & Display Orientation

CHAPTER 2 CONTROLS AND DISPLAY
EFD1000 VFR PFD Pilot’s Guide
Page 2-2
091-00028-001 ( )
2.1. Controls & Display Orientation
ATTITUDE DISPLAY
16 Attitude Display
17 Aircraft Reference Symbol
18
19 Roll Pointer
20 Slip/Skid Indicator
21 Altitude Tape
22 Selected Altitude Field (controls the Altitude Bug)
23 Altitude Alerter
24 Numerical Altitude Indication, Altitude Drum/
Pointer
25 Altitude Trend Vector
26 Altitude Bug
27
28
29
30
31
32 Airspeed Tape
33 Selected Airspeed Field (controls the Airspeed Bug)
34 Airspeed Bug
35 Numerical Airspeed Indicator, Airspeed Drum/
Pointer
36
37
Figure 2-1a
VFR PFD
CONTROLS
1 Reversion and Power Button
2 Range Buttons
3 Menu Button
4 1/2 Hot Key Menu 1 of 2 2/2 Hot Key Menu 2 of 2
1, 5
5 LTNG
4
– Data link Lightning
Overlay On/O
STRK
4
– WX-500 Strikes Overlay
CELL
4
– WX-500 Cells Overlay
6 360/ARC View NXRD
4
– Data Link Weather
Overlay On/O
7 GPSS - GPS Steering
2, 6
On/O
TRFC
4
– Trac Overlay On/O
8 BARO BARO
9 Right Knob, HDG, altitude bug
10 Right Button
11 CDI Navigation Source Select Button (Middle Button)
12 Left Button
13 Left Knob, course and air speed bug
14 Automatic Dimming Photocell
15 microSD Card Slot
