CHAPTER 5 CUSTOMIZING THE EFD1000 PFD
EFD1000 VFR PFD Pilot’s Guide
Page 5-2
091-00028-001 ( ) EFD1000 VFR PFD Pilot’s Guide
Page 5-3
091-00028-001 ( )
KEY DESCRIPTION OPTIONS
Barometer Pressure Setting Units of Measure in Hg or mB
Outside Air Temperature Units of Measure °C or °F
Clear WX-500 Strike/Cell Count
1,
Action
WX-500 Strike Test
1,
Action
Auto Range DISABLE or ENABLE
Table 5-2
Menu – GENERAL SETTINGS B
Figure 5-2
GENERAL SETTINGS B
1. PFD Only when congured with Stormscope® WX-500.
