CHAPTER 5 CUSTOMIZING THE EFD1000 PFD
EFD1000 VFR PFD Pilot’s Guide
Page 5-6
091-00028-001 ( ) EFD1000 VFR PFD Pilot’s Guide
Page 5-7
091-00028-001 ( )
KEY DESCRIPTION OPTIONS
VSPEEDS DISABLE or ENABLE
Va 0 to 450 or LOCKED
Vbg 0 to 450 or LOCKED
Vref 0 to 450 or LOCKED
Vr 0 to 450 or LOCKED
Table 5-6
Menu – VSPEEDS A
Figure 5-6
VSPEEDS A
Figure 5-7
VSPEEDS B
NOTE
When V Speeds are LOCKED at installation, the legend and set value are shown in gray.
Setting any of the above values to zero removes the aected V Speed.
KEY DESCRIPTION OPTIONS
Vx 0 to 450 or LOCKED
Vy 0 to 450 or LOCKED
Vlo 0 to 450 or LOCKED
Vle 0 to 450 or LOCKED
Table 5-7
Menu – VSPEEDS B
