EFD1000 VFR PFD Pilot’s Guide
Page xviii
091-00028-001 ( ) EFD1000 VFR PFD Pilot’s Guide
Page xix
091-00028-001 ( )
Term Example
Buttons REV Button, Range Buttons, MENU Button
Hot Keys / Menu Keys Five keys on the lower right of the display
Buttons CDI Navigation Source Select Button (Center Button)
Knobs Left (CRS) Knob, Right (HDG) Knob
Navigation Display
Data Bar
Airspeed, attitude, altitude display
Table 1
EFD1000 PFD Display, Knobs , Buttons, and Keys
Figure 1
EFD1000 PFD Display, Knobs , Buttons, and Keys
