CHAPTER 6 EXPANDED EMERGENCY AND ABNORMAL PROCEDURES
Perform an In-Flight AHRS Reset
1. Maintain straight and level ight.
2. Consider exiting IMC.
3. Fly by visual reference or by standby instruments.
4. Disconnect the autopilot.
5. Press the MENU Button.
6 Rotate the Right Knob to display the GENERAL SETTINGS A Menu page.
7. Press the AHRS RESET? Menu Key (Figure6-7).
A conrmation message displays, prompting the user to conrm the reset
request (Figure 6-8).
8. Press the AHRS Menu Key again to conrm the AHRS reset. The AHRS reset is
performed, and the conrmation messages clears.
9. Press the MENU Button to exit.
Figure 6-7
AHRS Reset Menu Key
Figure 6-8
AHRS Reset Conrmation Message
NOTE
Pressing any other key, button, or knob cancels the
AHRS reset and clears the conrmation message.
