EFD1000 VFR PFD Pilot’s Guide
Page 6-18
091-00028-001 ( ) EFD1000 VFR PFD Pilot’s Guide
Page 6-19
091-00028-001 ( )
CHAPTER 6 EXPANDED EMERGENCY AND ABNORMAL PROCEDURES
WARNINGS
Figure 6-16
Chevrons indicate Pitch Down
Figure 6-17
Chevrons indicate Pitch Up
When the Attitude Indicator display extreme pitch up or extreme pitch down attitudes, the red
chevrons indicate the direction to restore level ight.
Table 6-1
Warning Annunciations
