EFD1000 VFR PFD Pilot’s Guide
Page 6-20
091-00028-001 ( ) EFD1000 VFR PFD Pilot’s Guide
Page 6-21
091-00028-001 ( )
CHAPTER 6 EXPANDED EMERGENCY AND ABNORMAL PROCEDURES
CAUTION
Figure 6-20
GPS Invalid
Figure 6-21
RSM GPS
Presented when a congured GPS source’s data is invalid or unavailable. GPS# or RSM REVERSION
annunciations indicate the current GPS Basemap source
Figure 6-22
GPS Reversion
Figure 6-23
GPS Reversion Emergency
Figure 6-24
GPS Integrity Flag
Presented when the PFD’s Selected CDI Navigation Source is a GPS and that GPS is sending an
Integrity alert. See the GPS AFMS for more information
Figure 6-25
Altitude Caution
Presented to indicate the aircraft is reaching (steady) or deviating (ashing) from the preset altitude.
Figure 6-26
Decision Height Caution
Presented when a connected radio altimeter indicates it has reached the altitude set by the pilot.
See the Radio Altimeter AFMS for more information
1
1. Included in VFR to PRO upgrade
