EFD1000 VFR PFD Pilot’s Guide
Page 6-22
091-00028-001 ( ) EFD1000 VFR PFD Pilot’s Guide
Page 6-23
091-00028-001 ( )
CHAPTER 6 EXPANDED EMERGENCY AND ABNORMAL PROCEDURES
ADVISORY
Figure 6-30
REV Button O
Presented when the REV Button is pressed.
Figure 6-31
GPSS On
Presented when GPSS is enabled and the GPS source is valid. Either GPSS1 or GPSS2 may be
annunciated, depending on selection and the number of congured GPS navigators. This also
indicates the autopilot heading source
1
.
NOTE
GPSS will always reect the GPS Basemap source in the Navigation Display and follow its source.
1. Requires ACU option
