CHAPTER 1 WELCOME
EFD1000 VFR PFD Pilot’s Guide
Page 1-2
091-00028-001 ( ) EFD1000 VFR PFD Pilot’s Guide
Page 1-3
091-00028-001 ( )
Figure 1-3
Dual Display System: PFD & MFD
Figure 1-2
Single Display EFD1000 PFD System
The center of the EFD System is the EFD 1000 Primary Flight Display (PFD), which
replaces the traditional mechanical Attitude Indicator (AI) and Directional Gyro (DG),
Course Deviation Indicator or Horizontal Situation Indicator (HSI)
1
(Figure 1-2).
The PFD is available in three models—the EFD 1000 Pilot, EFD1000 VFR and the
EFD 1000 Pro.
Add an EFD500 (Figure 1-3) congured as a Multi-Function Display (MFD) and you
add the ability to display a variety of navigation and weather information, terrain and
obstacle data and trac information.
