CHAPTER 2 CONTROLS AND DISPLAY
EFD1000 VFR PFD Pilot’s Guide
Page 2-7
091-00028-001 ( )
Left Knob
SYNC Action
IAS Set to the current indicated airspeed.
CRS
VOR navigation
Course Pointer points to the VOR. CRS
value is the reciprocal of the current VOR
radial. The deviation bar centers with a
“TO” indication.
GPS
Course Pointer points to the active GPS
waypoint. The deviation bar centers with
a “TO” indication. (AUTOCRS must be
disabled).
GPS
AUTOCRS enabled
No eect.
Left Knob - Current State default setting: CRS
Cyan indicates eld is inactive.
Table 2-2
Left and Right Knob SYNC Description
