CHAPTER 2 CONTROLS AND DISPLAY
EFD1000 VFR PFD Pilot’s Guide
Page 2-22
091-00028-001 ( )
ATTITUDE DISPLAY
16 Attitude Display 27
17 Aircraft Reference Symbol 28
18 29
19 Roll Pointer 30
20 Slip/Skid Indicator 31
21 Altitude Tape 32 Airspeed Tape
22 Selected Altitude Field 33 Selected Airspeed Field
23 Altitude Alerter 34 Airspeed Bug
24 Numerical Altitude Value,
Altitude Drum/Pointer
35 Numerical Airspeed Value, Airspeed
Drum/Pointer
25 Altitude Trend Vector 36
26 Altitude Bug 37
Table 2-6
Attitude Display Components
33 22
32
35
16
19
20
21
17
23
34
26
25
24
Figure 2-27
Attitude Display Components
