CHAPTER 3 FLYING THE EFD1000 PRO PFD
EFD1000 VFR PFD Pilot’s Guide
Page 3-2
091-00028-001 ( ) EFD1000 VFR PFD Pilot’s Guide
Page 3-3
091-00028-001 ( )
FEATURE SETTING FEATURE SETTING
Selected
Altitude
Set as desired
Barometric
Pressure
(BARO) Hot
Key
Allows for BARO
adjustment
Map RNG
(Range)
Buttons
Set as desired
Left and Right
Buttons
No EFD 1000
VFR functionality
Barometric
Pressure
Setting Field
Adjustable
CDI
Navigation
Source Select
(Middle
Button)
Select as desired
Heading Bug
Value
Set as desired
Selected
Course (CRS)
Pointer Field
Set as desired
Compass
Mode Hot Key:
360 or ARC
Set as desired
GPS Steering
(GPSS) Hot
Key
1
on/o
Selected
Airspeed
Set as desired
Table 3-1 Basic PFD Settings
Figure 3-1
Basic PFD Settings
1. ACU and compatible NAV required
