CHAPTER 3 FLYING THE EFD1000 PRO PFD
EFD1000 VFR PFD Pilot’s Guide
Page 3-8
091-00028-001 ( ) EFD1000 VFR PFD Pilot’s Guide
Page 3-9
091-00028-001 ( )
Once the radios are available, we listen to the ATIS and learn that the local altimeter
setting is 30.15 and that Runway 8 is in use for departures.
First set the standby altimeter to 30.15, and then set the PFD barometric pressure
setting.
Set the Barometric Pressure
1. Press the BARO Hot Key. The BARO label above the Right Knob and Barometric
Pressure Setting Field appear in magenta - enabled for editing (Figure3-6).
2. Rotate the Right Knob clockwise to increase or counterclockwise to decrease
the value of the Barometric Pressure Setting Field.
3. Once the correct value is selected, press the BARO Hot Key or any knob,
button/key to exit the BARO function. After 10 seconds of inaction or if any
other button/key is pressed, the BARO function is disabled and the Right
Knob returns to normal operation (Figure3-7).
Figure 3-6
BARO Setting Field Enabled
Figure 3-7
BARO Setting Field Disabled
WARNING
Whenever there is a new altimeter setting, set both the
PFD and the standby altimeter.
