27
GigaX3112 Series Layer 3 Managed Switch
4.5.4 Mirroring
Mirroring, together with a network traffic analyzer, helps you monitor network
traffics. You can monitor the selected ports for egress or ingress packets.
Mirror:
Selects the mirrored port from selection panel. The selected port can
be mirrored for Ingress, Egress or Both of traffic.
Mirror Mode:
Enables or disables the mirror function for the selected group.
Stack ID:
For standalone switch, only ID 1 is available.
Monitor Port:
Receives the copies of all the traffics in the selected mirrored
ports.
The monitor port can not belong to any link aggregation group.
The monitor port can not operate as a normal switch port. It does
not switch packets or do address learning.
Click
OK
to make the setting send to the switch (HTTP server). Click
Reload
to
refresh the settings to current value.
Figure 26. Mirroring page (GigaX 3112F)
