Ch. 19. Air Temperature Controller Sec. 19.6. ATC Front Panel LEDs
ATC temperature control OFF: The ATC
power is on, the Cypher enclosure door is closed
and the ATC Feedback is OFF.
• This is a normal condition until the
feedback is activated in the software.
Normal Operation, ATC ON, and controlling
temperature. The ATC is on, The door is
closed and the ATC Feedback is ON.
• Normal condition where the system should
be.
Note If the ATC was just activated, the lights do
not indicate if stable feedback has been reached.
